Xerox PHASER 6010 Service Manual

10-34 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Wiring
IP Board
PL7.1.9
PWBA CC D
P/J1001 CON2
1
2
3
4
5
6
SG
CON1
1
2
12
INV_PW
INV_PW
SG
7
8
9
10
11
12
+12VDC
+3VDC
Home SEN
+5VDC
SG
/RESET
SH_R
SG
IIT Assembly
PL8.1.8
s6015-059
13
14
AFE_SDIO
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
AFE_SCLK
/AFE_SEN
16
17
18
19
20
21
RXIN0+
SG
RXIN1-
RXIN1+
22
23
24
25
26
27
DGND
RXIN2-
RXIN2+
SG
RXINCLK-
RXINCLK+
DGND
RXIN0-
28
29
LVDSCLK+
30
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
LVDSCLK-
SG
P/J1002
1
2
3
4
SCAN MOTB
SCAN MOT/A
SCAN MOTA
SCAN MOT/B
Scanner Motor
M
Lamp Inverter
Lamp

Xerox PHASER 6010 Specifications

General

Print Technology	Laser
Print Speed	Up to 12 ppm color / 15 ppm black
Print Resolution	1200 x 2400 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Standard Paper Capacity	150 sheets
Memory	128 MB
Paper Output Capacity	100 sheets
Duplex Printing	Manual
Maximum Paper Capacity	150 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Weight	24.3 lbs
