A-14 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Reference
IL OPEN 1. Power on the printer, and start the CE Diag Tool.
2. Click the CE Diag tab, and then select Digital Input.
3. Select the IL OPEN test, and click the OK button.
4. Click the Stop button to stop the test.
Test example:
[09:37]
Digital Input Mode = ENTRY
[09:37]
IL OPEN = LOW
STARTED = IL OPEN
[09:37]
IL OPEN = HIGH
STARTED = IL OPEN
[09:37]
IL OPEN = LOW
STARTED = IL OPEN
[09:37]
Digital Input Mode = EXIT
FAN ALARM Not used.
Test Procedure
