Use the Clean Toner procedure after running a low area coverage job followed by large area
coverage job, which caused toner agglomerates and clumps on the output prints. The press runs a
full-page halftone to purge the debris and any residual dry ink/toner from the system.
Note: It is recommended that you run a few test prints before performing the cleaning
procedure. After the Start Cleaning button is selected, the system automatically generates a
test print. This allows you to compare the before and after prints for image quality.
1. At the press control panel, log in as the administrator.
2. Press the Machine Status button.
3. Select the Tools tab.
4. Select System Settings→Common Service Settings→Maintenance.
5. Scroll through the Maintenance pages and select Clean Toner.
6. Select the desired dry ink/toner colors to clean.
If desired, you can select all the toner colors.
7. Press Start.
After the purge page prints, a Successfully Completed message appears.
8. To ensure that the problem is resolved, select Sample Print.
9. Select Close repeatedly until the main Tools screen appears.
10. Exit the administrator mode.
CCaalliibbrraattiinngg tthhee PPrreessss
Note: The information contained in this section is about calibrating the press only.
For information about calibrating the print server, refer the System Administrator Guide for the press.
Also refer to the print server documentation.
FFuullll WWiiddtthh AArrrraayy
Accessed from the press control panel, the Full Width Array feature calibrates the print engine only.
The in-line Full Width Array adjusts print engine color controls, provides image density uniformity, and
enables print server calibration and profiling without the need to use an external spectrophotometer.
The Full Width Array uses xerographic parameters and diagnostics to analyze the finished image and
correct errors in output color and density uniformity. This feature uses internal color calibration strips
(or tiles) as reference for known colors of a test pattern. These color values are automatically adjusted
to produce accurate and consistent reproductions.
The Full Width Array is located in the paper path after the fuser and contains an inline scanner to
provide print engine adjustments. The adjustments ensure uniformity of dry ink/toner on prints and
image alignment.
The Full Width Array provides these two adjustments:
• Automatic Density Uniformity Adjustment: Run this image quality adjustment when the printed
output density is inconsistent (non-uniform) within the printed page. Non-uniform, inconsistent
density may appear as faded colors on portions of the printed page (jobs running light and dark).
236
