Xerox Versant 4100 Press - Loading Envelopes in Trays 6 and 7 with the Optional Envelope Support Kit

Loading Envelopes in Trays 6 and 7 with the Optional Envelope Support Kit
Note: If available, use the optional Envelope Support Kit to feed and print envelopes from
Trays 6 or 7.
The Envelope Support Kit enables a greater quantity of envelopes to be loaded and printed from the
tray.
1. Slowly open one of the paper trays until it stops and remove the paper.
2. Move the paper guides out to their largest position.
3. Locate the Envelope Support Kit.
4. Install the L-shape envelope bracket:
a. Sit the bracket on the locating pins on the upper frame and in the grooves on the bottom of
the tray.
b. Tighten the thumb screw so it locks the L-shape envelope bracket in place.
