Xerox Versant 4100 Press - Alignment Profile

AAlliiggnnmmeenntt PPrrooffiillee
Table 3.1 Registration
Option or
Setting
Default
Value
Adjust-
ment
Step
Incre-
ments
Available
Range
Recommended Incremental
Adjustment
Side 1, Side 0.0 0.1 -2.0 to 2.0 mm Determined by test print output
Side 1, Lead 0.0 0.1 -2.0 to 2.0 mm Determined by test print output
Side 2, Side 0.0 0.1 -2.0 to 2.0 mm Determined by test print output
Side 2, Lead 0.0 0.1 -2.0 to 2.0 mm Determined by test print output
Table 3.2 Perpendicularity
Option or
Setting
Default
Value
Adjust-
ment
Step
Incre-
ments
Available
Range
Recommended Incremental
Adjustment
Side 1 0.0 0.1 -1.0 to 1.0 mm Determined by test print output
Side 2 0.0 0.1 -1.0 to 1.0 mm Determined by test print output
Table 3.3 Skew
Option or
Setting
Default
Value
Adjust-
ment Step
Incre-
ments
Available
Range
Recommended Incremental
Adjustment
Side 1 0.0 0.1 -1.0 to 1.0 mm Determined by test print output
Side 2 0.0 0.1 -1.0 to 1.0 mm Determined by test print output
