2. Pull out the Saddle Stitch Unit 3 toward you until it stops.
3. While holding the tabs on the staple cartridge, pull out the cartridge to remove it.
Note: There are two booklet staple cartridges provided. Check the message to see which
cartridge needs replacing.
4. While holding the tabs on the new staple cartridge, push in the cartridge until it seats.
Note: Make sure that the marks are aligned.
