3. Rotate knob 2f clockwise (1) and remove jammed paper (2).
Note: Grasp the lead edge of the jammed sheet and gently pull out the sheet to remove it.
4. If you have difficulty removing the jammed sheet, grasp the top edge at the inner-right side of
the sheet and gently pull out the sheet to remove it.
5. Return levers 2e (1), 2d (2) and 2c (3) to their original positions.
6. Close the trimmer upper cover.
7. If the press indicates there are additional paper jams, follow the instructions to clear the paper
and to resume printing.
380
Xerox
®
Versant
®
4100 Press
User Documentation
Troubleshooting
