Xerox WorkCentre 7132 User Guide

Properties
Xerox WorkCentre 7132 User Guide 195
Protocol Settings NetWare
Allows you to configure the settings for NDS, transport protocol and
SLP, as follows.
Host Name – Enter the host name.
Active Mode – Selects the Active Mode for the printer when using
NetWare.
• Bindery: PServer Mode: Select this when using the printer server
mode in bindery service.
• Directory: PServer Mode: Select this when using the printer server
mode in directory service.
File Server Name – Enter the file server name.
Polling Interval – Allows you to set the time interval from when print
data enter the print queue until printing starts.
Number of searches – Enter the maximum number of searches.
Password – Enter the print server (PServer) password.
Re-enter Password – Allows you to verify the PServer password by
re-entering the same password.
TBCP Filter – This is only displayed when PostScript is enabled.
NDS – Configure the NDS settings.
Tree Name – Enter the tree name.
Context Name – Enter the context name of the Print Server Object.
Up to 511 characters can be entered, with the exception of + (plus
sign), \ (backslash), and ~ (tilde).
Transport Protocol (IPX/SPX) – Configure the IPX/SPX settings.
Frame Type – Select the frame type.
• Auto: Automatically configures the active frame type.
• Ethernet II: Selects Ethernet frame type.
• Ethernet 802.3: Selects IEEE802.3 frame type.
• Ethernet 802.2: Selects IEEE802.3/IEEE802.2 frame type.
• Ethernet SNAP: Selects IEEE802.3/IEEE802.2/SNAP frame type.
Network Address – Displays the network address in the
XXXXXXXX:XXXXXXXXXXXX format.
SLP – SLP will only be displayed when NetWare is selected in Port
Status and TCP/IP is selected as the Transport Protocol.
Active Discovery – Allows you to enable or disable the automatic
detection of the SLP directory agent.
Feature Setting items
