Layout Adjustment
Xerox WorkCentre 7132 User Guide 65
Left Page then Right
Copies both pages of an open book in the direction from left to right.
Right Page then Left
Copies both pages of an open book in the direction from right to left.
Top Page then Bottom
Copies both pages of an open book in the direction from top to bottom.
Start Page & End Page
Displays the [2 Sided Book Copy - Start Page & End Page] screen.
Specifies the start page and the end page for copying. The specified page sides must
be identified using the bound original.
Binding Erase
Erases printing of the center binding area of the book that tends to be shadowed due
to the fold in the pages. Use the scroll buttons to specify the area to be erased from the
center of an open book within the range of 0-50 mm (0.0-2.0 inches) in 1mm (0.1 inch)
increments.
Original Size
This feature allows you to set the size of the document automatically, to select from a
list of preset sizes, or to mix different size documents. If you select a preset size,
documents will be copied according to the specified size regardless of their actual size.
1. Select [Original Size] on the
[Layout Adjustment] screen.
2. Select the required option.
3. Select [Save].
Auto Detect
Automatically detects the size of standard sized documents.
Manual Size Input
Allows you to select the input size from the 11 preset standard sizes in portrait or
landscape orientations, or select a custom size within the ranges of 15-297 mm (0.6-
11.7 inches) for length and 15-432 mm (0.6-17.0 inches) for width. The presets are set
up by the Key Operator.
Mixed Sized Originals
Allows you to copy more than one original size document. The machine senses the
mixed sized originals automatically, and copies each document at the same size as the
originals. Load different size documents, with top left corners aligned, into the
Document Feeder.
