Xerox WorkCentre 7132 User Guide

SMart Kit (Customer Replaceable Units)
Xerox WorkCentre 7132 User Guide 369
3. Fasten the unit into position by
rotating the screws clockwise.
4. Close the side cover.
5. Connect the power cord, then turn the power switch on of the machine.
6. Select [Fuser SMart Kit] on the [Consumbles Status] screen.
When the [Consumbles Status] screen does not appear on the touch screen, press the
<Machine Status> button on the control panel, select the [Supplies] tab on the touch
screen, then select [Fuser SMart Kit].
7. Select [Reset Counter] on the
screen.
8. Select [Yes] to reset the counter.
Transfer Belt Cleaner
The Transfer Belt Cleaner lasts approximately 100,000 copies and prints. The machine
will display a warning message approximately 1,500 copies and prints before the
Downloaded From ManualsPrinter.com Manuals

Xerox WorkCentre 7132 Specifications

General

Brand	Xerox
Model	WorkCentre 7132
Category	All in One Printer
Language	English
