Stapler Faults

Xerox WorkCentre 7132 User Guide 393

Stapler Faults

Below describes stapler troubles when the Finisher (optional) is installed.

Follow the procedures on the following pages when copies are not stapled or when

staples are bent. Contact your Xerox Welcome Center if the problem persists after you

have tried the following solutions.

If staples are stapled on the copies in the manner shown in the figures below, contact

your Xerox Welcome Center.

Unstapled

Bent staple

One side of staple rising up Staple bent in reverse direction

Flattened staple Entire staple rising up

Staple rising up with

center pressed in
