Xerox WorkCentre 7132

14 Maintenance
366 Xerox WorkCentre 7132 User Guide
Inserting the New Second Bias Transfer Roll Unit
1. Remove the new Second Bias
Transfer Roll unit from its box,
and make sure that parts on
both ends of the Second Bias
Transfer Roll unit are pushed in
properly as shown in the
diagram.
NOTE: Failing to properly push in
those parts on both ends may result
in paper jams or poor performance.
2. Insert the unit into the machine.
3. Place the unit in the machine,
aligning the arrow indicators.
4. Fasten the unit into position by
rotating the screws clockwise.
