Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-89
SCPI Commands
:PAGE:CHANnels[:CDEFinition]:SMU<n>:FUNCtion
:PAGE:CHANnels[:CDEFinition]:SMU<n>:FUNCtion
This command sets the function (FCTN) of SMU<n>. This command also has a
query form.
The value <n> is required to specify the SMU number. Valid SMU numbers are
SMU1 through SMU6, depending on the configuration.
At *RST, this value is set to:
Syntax :PAGE:CHANnels [ :CDEFinition] :SMU<n>:FUNCtion VAR1 | VAR2 | VARD |
CONStant
:PAGE:CHANnels [ :CDEFinition] :SMU<n>:FUNCtion?
Parameter
Query response VAR1 | VAR2 | VARD | CONS | DIS <newline><^END>
If an SMU is not used, the response data may be DIS(DISable).
Example OUTPUT @Hp4155;":PAGE:CHAN:SMU1:FUNC VAR1"
OUTPUT @Hp4155;":PAGE:CHAN:SMU1:FUNC?"
ENTER @Hp4155;A$
SMU FUNCTION
SMU1 CONStant
SMU2 VAR2
SMU3 VAR1
SMU4 CONStant
SMU5 and SMU6 Not defined
Parameter Type Explanation
VAR1 character VAR1 function (available for sweep and QSCV)
VAR2 character VAR2 function (sweep mode only)
VARD character VAR1’ function (sweep mode only)
CONStant character Constant
