Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-219
SCPI Commands
:PAGE:MEASure[:SWEep]:CONStant:SMU<n>:COMPliance
:PAGE:MEASure[:SWEep]:CONStant:SMU<n>:COM
Pliance
This command sets the constant COMPLIANCE value of SMU<n> for the sweep
measurement.
<n> is required to specify SMU number. Valid SMU numbers are SMU1 through
SMU6, depending on the configuration.
You use this command only if the function of the specified SMU is CONStant and
the mode is not COMMon.
At *RST, this value is:
Syntax :PAGE:MEASure [:SWEep] :CONStant:SMU<n>:COMPliance compliance |
MINimum | MAXimum
Parameter
Query response compliance <newline><^END>
compliance is NR3 response data type.
Example OUTPUT @Hp4155;":PAGE:MEAS:CONS:SMU1:COMP 0.1"
OUTPUT @Hp4155;":PAGE:MEAS:CONS:SMU1:COMP MAX"
OUTPUT @Hp4155;":PAGE:MEAS:CONS:SMU1:COMP?"
ENTER @Hp4155;A
OUTPUT @Hp4155;":PAGE:MEAS:CONS:SMU1:COMP? MAX"
ENTER @Hp4155;A
SMU COMPLIANCE
SMU1 not defined
SMU2 2 V
SMU3 100 mA
SMU4 100 mA
SMU5 and SMU6 not defined
Parameter Type Explanation
compliance numeric -200 to 200 V or -1 to 1 A. The range of this value
depends on the type of SMU.
