Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-97
SCPI Commands
:PAGE:CHANnels[:CDEFinition]:VSU<n>:FUNCtion
:PAGE:CHANnels[:CDEFinition]:VSU<n>:FUNCtion
This command sets the function (FCTN) of VSU<n>.
<n> is required to specify VSU number. Valid VSU numbers are VSU1 through
VSU2.
At *RST, this value is CONStant.
Syntax :PAGE:CHANnels [ :CDEFinition] :VSU<n>:FUNCtion VAR1 | VAR2 | VARD |
CONStant
Parameter
Query response VAR1 | VAR2 | VARD | CONS | DIS <newline><^END>
If VSU is not used, the response data may be DIS(DISable).
Example OUTPUT @Hp4155;":PAGE:CHAN:VSU:FUNC VAR1"
OUTPUT @Hp4155;":PAGE:CHAN:VSU:FUNC?"
ENTER @Hp4155;A$
Parameter Type Explanation
VAR1 character VAR1 function
VAR2 character VAR2 function
VARD character VAR1' function
CONStant character constant
