Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-225
SCPI Commands
:PAGE:MEASure[:SWEep]:SSTop
OUTPUT @Hp4155;":PAGE:MEAS:PULS:WIDTH MAX"
OUTPUT @Hp4155;":PAGE:MEAS:PULS:WIDTH?"
ENTER @Hp4155;A
OUTPUT @Hp4155;":PAGE:MEAS:PULS:WIDTH? MAX"
ENTER @Hp4155;A
:PAGE:MEASure[:SWEep]:SSTop
This command sets the sweep stop mode for an abnormal status.
The abnormal statuses that can be detected are as follows:
• SMU reaches its compliance setting.
• Current of VSU exceeds ±100 mA.
• SMU or VSU oscillates.
• A/D converter overflow occurs.
• Average current of PGU exceeds ±100 mA.
At *RST, this value is OFF.
If you set the SERIES RESISTANCE of SMU<n> to a non-zero value by
:PAGE:CHANnels[:CDEFinition]:SMU<n>:SRESistance, this value is
automatically changed to COMP.
Syntax :PAGE:MEASure [ :SWEep] :SSTop ABNormal | COMPliance | OFF
Parameter
If you set the power compliance for VAR1, you cannot specify OFF.
Query response OFF | ABN | COMP <newline><^END>
Example OUTPUT @Hp4155;":PAGE:MEAS:SST ABN"
OUTPUT @Hp4155;":PAGE:MEAS:SST?"
ENTER @Hp4155;A$
Parameter Type Explanation
ABNormal character Stop sweep if abnormal status is detected.
COMPliance character Stop sweep if some SMU reaches its compliance
setting.
OFF character Continue sweep even if abnormal status is detected.
