5-116 Agilent 4155C/4156C SCPI Command Reference, Edition 1

SCPI Commands

:PAGE:DISPlay:ANALysis:LINE(1|2):POINt(1|2):Y

This command specifies the Y coordinate of the desired point.

If POINt(1|2):MODE is OPLot (not XY), this parameter is ignored.

At *RST, this value is undefined.

Syntax :PAGE:DISPlay:ANALysis:LINE(1 | 2):POINt(1 | 2):Y y_expression

Parameter

Query response y_value <newline><^END>

y_value is string response data, but does not contain double quote characters at the

beginning and end of the string.

Example OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:POIN1:Y '0.1'"

OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:POIN1:Y?"

ENTER @Hp4155;A$

:PAGE:DISPlay:ANALysis:LINE(1|2):TANGent:AFTer

This command specifies the start position (TANG:AFT var_name, expr) to search

for the point (TANG:POS var_name, expr) at which to draw the tangent line.

If LINE(1|2):MODE is not TANGent, this parameter is ignored.

At *RST, this value is undefined.

Syntax :PAGE:DISPlay:ANALysis:LINE(1 | 2):TANGent:AFTer var_name, expr

Parameter

Query response var_name, expr <newline><^END>

Parameter Type Explanation

y_expression string expression of the Y coordinate point

Parameter Type Explanation

var_name string data variable name

expr string condition expression
