5-114 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:DISPlay:ANALysis:LINE(1|2):POINt(1|2):MODE
:PAGE:DISPlay:ANALysis:LINE(1|2):POINt(1|2):MO
DE
This command selects the point specification mode for line.
If LINE(1|2):MODE is TANGent, then POINt(1|2) are not used.
If LINE(1|2):MODE is GRADient, then POINt2 is not used.
At *RST, this value is XY.
Syntax :PAGE:DISPlay:ANALysis:LINE(1 | 2):POINt(1 | 2):MODE XY | OPLot
Parameter
Query response XY | OPL <newline><^END>
Example OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:POIN1:MODE XY"
OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:POIN1:MODE?"
ENTER @Hp4155;A$
:PAGE:DISPlay:ANALysis:LINE(1|2):POINt(1|2)
:POSition
This command specifies the desired point by using a condition expression.
If POINt(1|2):MODE is XY (not OPLot), this parameter is ignored.
At *RST, this value is undefined.
Syntax :PAGE:DISPlay:ANALysis:LINE(1 | 2):POINt(1 | 2):POSition var_name, expr
Parameter
Parameter Type Explanation
XY character specify the X-Y coordinates directly
OPLot character specify by a condition expression
Parameter Type Explanation
var_name string data variable name
expr string condition expression
