Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-17
SCPI Commands
:DATA|:TRACe:UNIT
:DATA|:TRACe:UNIT
This command sets the unit for data of the specified user variable.
The user variable must first be defined by the :DATA | :TRACe:DEFine or
:PAGE:CHANnels:UVARiable:DEFine command, or on the CHANNELS: USER
VARIABLE DEFINITION page.
Syntax :DATA | :TRACe:UNIT user_variable_name ,unit
Parameter
Query response unit <newline><^END>
Example OUTPUT @Hp4155;":TRAC:UNIT 'Vdata','mV'"
OUTPUT @Hp4155;":TRAC:UNIT? 'Vdata'"
ENTER @Hp4155;A$
Parameter Type Explanation
user_variable_name string or
character
user variable name to specify unit for
unit string unit of the user variable data
