5-148 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:KSW Commands
:PAGE:KSW commands set the KNOB SWEEP page. These commands are not
available when the 4155C/4156C screen is set to the update disable state by :DISP
OFF (or 0) command. To use :PAGE:KSW commands, enter :DISP ON (or 1)
command.
Command Parameter
:PAGE
:KSWeep
:CURSor
:X <numeric_value>
:Y <numeric_value>
:DISPlay
:DIRection
:X NORMal | REVerse
:Y NORMal | REVerse
:GRID 0 | 1 | OFF | ON
:REGion
:X POSitive | NEGative | BIPolar
:Y POSitive | NEGative | BIPolar
[:MENU]
:SCOPy
:VAR1
:EXTent <numeric_value>
:MODE SINGle | DOUBle
:POLarity POSitive | NEGative | BIPolar
:POINts <numeric_value>
:RANGe <numeric_value>
:STIMe <numeric_value>
:Y <var_name>
