5-186 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:MEASure:PGUSetup:PULSe:PGU<n>:TRAiling
:PAGE:MEASure:PGUSetup:PULSe:PGU<n>:TRAilin
g
This command sets the trailing-edge transition time (TRAILING TIME) of
PGU<n>.
<n> is required to specify PGU number. Valid PGU numbers are PGU1 through
PGU2.
You use this command only if the specified PGU is set to VPULse mode (not V) by
the :PAGE:CHAN:PGU<n>:MODE command.
At *RST, this value is 100 ns.
Syntax :PAGE:MEASure:PGUSetup:PULSe:PGU<n>:TRAiling trailing_time | MINimum
| MAXimum
Parameter
Query response trailing_time <newline><^END>
trailing_time is NR3 response data type.
Example OUTPUT @Hp4155;":PAGE:MEAS:PGUS:PULS:PGU1:TRA 0.001"
OUTPUT @Hp4155;":PAGE:MEAS:PGUS:PULS:PGU1:TRA MIN"
OUTPUT @Hp4155;":PAGE:MEAS:PGUS:PULS:PGU1:TRA?"
ENTER @Hp4155;A
OUTPUT @Hp4155;":PAGE:MEAS:PGUS:PULS:PGU1:TRA? MIN"
ENTER @Hp4155;A
Parameter Type Explanation
trailing_time numeric 1E-7 to 1E-2 (s)
