Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-295
SCPI Commands
:STATus:OPERation:PTRansition
:STATus:OPERation:PTRansition
This command sets the positive transition filter for the Operation Status
"CONDITION" register.
Syntax :STATus:OPERation:PTRansition register
Parameter
Query response register <newline><^END>
register is a decimal integer value, which is the sum of the binary-weighted values,
in NR1 response data format.
Semantics If a bit in the positive transition filter is set to 1, then a 0 to 1 transition in the
corresponding bit of the Operation Status "CONDITION" register causes a 1 to be
written in the corresponding "EVENT" register.
Example OUTPUT @Hp4155;":STAT:OPER:PTR 16384"
OUTPUT @Hp4155;":STAT:OPER:PTR #H4000"
OUTPUT @Hp4155;":STAT:OPER:PTR #Q40000"
OUTPUT @Hp4155;":STAT:OPER:PTR #B100000000000000"
OUTPUT @Hp4155;":STAT:OPER:PTR?"
ENTER @Hp4155;A
:STATus:PRESet
This command presets the event enable (MASK) register and TRANSITION
FILTER registers of the Operation Status, Questionable Status, and Emergency
Status registers.
This command does not have query form.
Syntax :STATus:PRESet
Example OUTPUT @Hp4155;":STAT:PRES"
Parameter Type Explanation
register numeric or
non-decim
al numeric
decimal integer, hexadecimal, octal, or binary value
that is the sum of the binary-weighted values for the
desired bits.
