5-26 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:DISPlay:CMAP:COLor<n>:HSL
:DISPlay:CMAP:COLor<n>:HSL
This command sets the instrument's color map based on the
Hue/Saturation/Luminance color model.
<n> is required to specify the color numbers. Valid COLor numbers are COLor1
through COLor15.
Syntax :DISPlay:CMAP:COLor<n>:HSL hue | MINimum | MAXimum,
sat | MINimum | MAXimum, lum | MINimum | MAXimum
Parameter
Color
Number
Explanation
Color
Number
Explanation
1 Background 9 Advisory
2 Softkey Background 10 Y1 Axis
3 Active Field Background 11 Y2 Axis
4 Graph Background 12 Marker/Cursor/Line
5 Foreground 13 Active Mkr/Csr/Lne
6 Active Field Foreground 14 Overlay
7 Title 15 Grid
8Frame
Parameter Type Explanation
hue numeric Hue ranges circularly from 0 to 1 with a value of 0
resulting in the same hue as a value of 1. The
approximate color progression is (starting at 0): red,
orange, yellow, green, cyan, blue, magenta, and back
to red.
sat numeric Saturation is the amount of pure color to be mixed
with white. The saturation value ranges from 0 to 1,
with 0 specifying no color (only white or gray,
depending on intensity) and 1 specifying no white.
lum numeric Luminance specifies the brightness per unit area of
color. The luminance value ranges from 0 to 1. A
luminance of 0 results in black; a luminance of 1
results in the brightest color variable.
