Agilent Technologies 4156C Command Reference

5-136 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:GLISt[:GRAPhics]:DISPlay:OVERlay[:PLANe]
:PAGE:GLISt[:GRAPhics]:DISPlay:OVERlay[:PLANe
]
This command overlays data in the selected internal memory onto the plotting area.
At *RST, this value is OFF.
Syntax :PAGE:GLISt [ :GRAPhics] :DISPlay:OVERlay [ :PLANe] memory_no | OFF | 0
Parameter
Query response memory_no <newline><^END>
memory_no is NR1 response data.
Example OUTPUT @Hp4155;":PAGE:GLIS:DISP:OVER 1"
OUTPUT @Hp4155;":PAGE:GLIS:DISP:OVER?"
ENTER @Hp4155;A
:PAGE:GLISt[:GRAPhics]:DISPlay:OVERlay:SINFo
This command sets the "show overlay information" mode to on or off.
At *RST, this value is OFF.
Syntax :PAGE:GLISt [ :GRAPhics] :DISPlay:OVERlay:SINFo OFF | ON | 0 | 1
Parameter
Query response 0 | 1 <newline><^END>
Example OUTPUT @Hp4155;":PAGE:GLIS:DISP:OVER:SINF ON"
OUTPUT @Hp4155;":PAGE:GLIS:DISP:OVER:SINF?"
ENTER @Hp4155;A
Parameter Type Explanation
memory_no numeric 1 to 4
OFF or 0 boolean overlay plane is off
Parameter Type Explanation
OFF or 0 boolean "show overlay information" mode is off
ON or 1 boolean "show overlay information" mode is on
