5-118 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:DISPlay:ANALysis:LINE(1|2):TANGent :POSition
:PAGE:DISPlay:ANALysis:LINE(1|2):TANGent
:POSition
This command specifies the point at which to draw a tangent line. The point is
specified by a condition expression.
If LINE(1|2):MODE is not TANGent, this parameter is ignored.
At *RST, this value is undefined.
Syntax :PAGE:DISPlay:ANALysis:LINE(1 | 2):TANGent:POSition var_name, expr
Parameter
Query response var_name, expr <newline><^END>
var_name and expr are string response data, but do not contain double quote
characters at the beginning and end.
Example OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:TANG:POS 'DGM','MA
X(DGM)*0.01'"
OUTPUT @Hp4155;":PAGE:DISP:ANAL:LINE1:TANG:POS?"
ENTER @Hp4155;A$
:PAGE:DISPlay:ANALysis:MARKer:AFTer
This command specifies the start position (MARK:AFT var_name, expr) to search
for the marker position specified by (MARK:POS var_name, expr).
At *RST, this value is undefined.
Syntax :PAGE:DISPlay:ANALysis:MARKer:AFTer var_name, expr
Parameter Type Explanation
var_name string data variable name
expr string condition expression
