5-198 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:MEASure:QSCV:RANGe
:PAGE:MEASure:QSCV:RANGe
This command sets the measurement RANGE of the measurement channel used in
the Quasi-static CV measurements. This command also has a query form.
At *RST, this value is set to 1E-9.
Syntax :PAGE:MEASure:QSCV:RANGe range | MINimum | MAXimum
:PAGE:MEASure:QSCV:RANGe?
Parameter
Query response range <newline><^END>
range is an NR3 response data type.
Example OUTPUT @Hp4155;":PAGE:MEAS:QSCV:RANG MAX"
OUTPUT @Hp4155;":PAGE:MEAS:QSCV:RANG?"
ENTER @Hp4155;A
Parameter Type Explanation
range numeric 10E-12, 100E-12, 1E-9, or 10E-9 for the 4156C.
1E-9 or 10E-9 for the 4155C, MPSMU, HPSMU.
