Agilent 4155C/4156C SCPI Command Reference, Edition 1 5-275
SCPI Commands
:PAGE:STRess:SETup:PULSe:PGU<n>:PEAK
:PAGE:STRess:SETup:PULSe:PGU<n>:PEAK
This command sets the PEAK VALUE of PGU<n> for stress.
<n> is required to specify PGU number. Valid PGU numbers are PGU1 through
PGU2.
The mode of the specified PGU must be VPULse.
At *RST, this value is 0.1 V.
Syntax :PAGE:STRess:SETup:PULSe:PGU<n>:PEAK peak | MINimum | MAXimum
Parameter
Query response peak <newline><^END>
peak is NR3 response data type.
Example OUTPUT @Hp4155;":PAGE:STR:SET:PULS:PGU1:PEAK 5"
OUTPUT @Hp4155;":PAGE:STR:SET:PULS:PGU1:PEAK MAX"
OUTPUT @Hp4155;":PAGE:STR:SET:PULS:PGU1:PEAK?"
ENTER @Hp4155;A
OUTPUT @Hp4155;":PAGE:STR:SET:PULS:PGU1:PEAK? MAX"
ENTER @Hp4155;A
Parameter Type Explanation
peak numeric -40 to 40 V
