5-188 Agilent 4155C/4156C SCPI Command Reference, Edition 1
SCPI Commands
:PAGE:MEASure:QSCV:CINTeg
:PAGE:MEASure:QSCV:CINTeg
This command sets the integration time for the capacitance measurement in the
Quasi-static CV measurement mode. The value is rounded as follows:
integration time = nplc / selected line frequency
where, nplc means the number of power line cycle. The value must be integer in the
range: 2 to 20000.
At *RST, this value is 5 / selected line frequency, so a 50 Hz line frequency has an
integration time of 0.1 s , and a 60 Hz line frequency has an integration time of
approximately 0.083 s.
This command also has a query form.
Syntax :PAGE:MEASure:QSCV:CINTeg integ_time
:PAGE:MEASure:QSCV:CINTeg?
Parameter
Query response integ_time <newline><^END>
integ_time is an NR3 response data type.
Example OUTPUT @Hp4155;":PAGE:MEAS:QSCV:CINT 0.4"
The above example sets the integration time to 0.4 s (=20/50=24/60) for both 50 Hz
and 60 Hz line frequencies.
OUTPUT @Hp4155;":PAGE:MEAS:QSCV:CINT?"
ENTER @Hp4155;A
Parameter Type Explanation
integ_time numeric Integration time in seconds.
0.04 to 400 s at 50 Hz line frequency.
0.033333 to 333.33 s at 60 Hz line frequency.
