4 Triggering
134 InfiniiVision 7000B Series Oscilloscopes User’s Guide
5 If you select an edge term, one channel must be set to a rising edge or
a falling edge. All other channel edges will be set to don’t care (X).
a Press the Channel softkey (or rotate the Entry knob) to select the
channel.
As you select a channel, the channel is highlighted in the selected
pattern list shown in the waveform area.
b Then press
the X softkey to select rising edge or falling
edge. All other channels will be defaulted to don’t care (X).
If you want to reassign an edge to a different channel, repeat the
above step. The value of the original channel edge will be defaulted
to X (don't care).
Define the “Trigger on” Stage
1 Press the Stage softkey and select Trigger on:.
Trigger on: is the next stage in the trigger sequence. When you select
the Stage Trigger on: softkey, the next softkey to the right will display
Trigger: and give you a list of the terms you can define for the Trigger
on: stage. The Trigger on: stage can be set to one of the following
conditions:
• Pattern 2 Entered — A pattern is entered on the last edge that makes
the pattern true (logical AND).
• Pattern 2 Exited — A pattern is exited on the first edge that makes the
pattern false (logical NAND).
• Edge 2
• Pattern 2 and Edge 2
• Nth Edge 2
• Nth Edge 2 (no re-find)
2 Press the Trigger: softkey and select a stage to trigger on.
If the term(s) used in the “Find:” Sequence Stage condition are set to “don’t care,” the
oscilloscope will not trigger. At least one term in the stage must be set to a value other than
X (don’t care).
