Agilent Technologies 7000B Series User Manual

Displaying Waveforms 3
InfiniiVision 7000B Series Oscilloscopes User’s Guide 67
Figure 2 Example of centering a signal on the display
Figure 3 Signal centered on the display
4 Press the [Cursors] key.
5 Set the Y2 cursor to the top of the signal, and set Y1 to the bottom of
the signal.
sin
A
B
---
or
C
D
----
=
A
B
D
C
Signal must
be centered in
“X”
