Getting Started 1
InfiniiVision 7000B Series Oscilloscopes User’s Guide 37
Front Panel Control and Connector Descriptions
1. Power Switch Press once to switch power on; press again to switch
power off. See page 29.
2. USB Host Port This port is for connecting USB mass storage devices or
printers to the oscilloscope.
Connect a USB compliant mass storage device (flash drive, disk drive, etc.)
to store or recall oscilloscope setup files or waveforms.
To print, connect a USB compliant printer. For more information about
printing see “To print the oscilloscope’s display” on page 220.
You can also use the USB port to update the oscilloscope’s system
software when updates are available.
You do not need to take special precautions before removing the USB
mass storage device from the oscilloscope (you do not need to “eject” it).
Simply unplug the USB mass storage device from the oscilloscope when
the file operation is complete.
For more information about saving to a USB mass storage device see
“Saving and Recalling Data” on page 206.
3. Probe Compensation Terminals Use the signal at this terminal to match a
probe’s input capacitance to the oscilloscope channel to which it is
connected. See page 56.
4. Channel Input BNC Connector Attach the oscilloscope probe or BNC cable
to the BNC connector. This is the channel’s input connector.
Do not connect a host computer to the oscilloscope’s USB host port
Use the device port. A host computer sees the oscilloscope as a device, so connect the
host computer to the oscilloscope’s device port (on the rear panel). See “Web
Interface” on page 239.
