18 Oscilloscope Utility Settings
384 InfiniiVision 7000B Series Oscilloscopes User’s Guide
If you need to switch Antialiasing off, press [Utility] > Options > Preferences
and press the Antialiasing softkey to switch the feature off. The displayed
waveforms will be more susceptible to aliasing.
To set up the screen saver
The oscilloscope can be configured to turn on a display screen saver when
the oscilloscope has been idle for a specified length of time.
1 Press [Utility] > Options > Preferences > Screen Saver to display the Screen
Saver Menu.
2 Press the Saver softkey to select the screen saver type.
The screen saver can be set to Off, to display any of the images shown
in the list, or can display a user- defined text string.
If User is selected, press the Spell softkey to select the first character of
the text string. Use the Entry knob to choose a character. Then press
the Enter softkey to advance to the next character and repeat the
process. The resultant string is displayed in the “Text =” line above the
softkeys.
3 Turn the Entry knob to select the number of minutes to wait before the
selected screen saver activates.
When you turn the Entry knob, the number of minutes is displayed in
the Wait softkey. The default time is 180 minutes (3 hours).
Select
characters
Advance to next
character
List of characters displayed
when Entry knob is turned
User-defined
text string
