Saving, Recalling, and Printing 6
InfiniiVision 7000B Series Oscilloscopes User’s Guide 215
Table 6 Recommended Signal Mapping
To save a waveform and/or setup to a USB mass storage
device
1 Insert a USB mass storage device into the front or rear USB device
port.
2 Press the [Save/Recall] key.
3 Press the Save softkey. The proposed file name will be shown in the
“Save to file” prompt above the Save softkey. (If you want to change the
file name, press the File Name softkey. See “Creating a new file
name” on page 209 for details.)
Label Signal Scope Channel Maps to Logic
Analyzer Channel
Tx R S 2 3 2 Tx C h 1 D 0
RxRS232 Rx Ch2 D1
I2C Data Ch1 D0
I2C Clk Ch2 D1
SPI2 (2-wire) Clk Ch1 D0
SPI2 Data Ch2 D1
SPI3 (3-wire) ~Chip Select Ch1 D0
SPI3 Clk Ch2 D1
SPI3 Data Ch3 D2
SPI4 (4-wire) ~Chip Select Ch1 D0
SPI4 Clk Ch2 D1
SPI4 DataIn Ch3 D2
SPI4 DataOut Ch4 D3
CANDataCh1 D0
LIN Data Ch1 D0
