Getting Started 1
InfiniiVision 7000B Series Oscilloscopes User’s Guide 31
Recall the Default Oscilloscope Setup
To recall the default oscilloscope setup:
• Press [Default Setup].
The default setup restores the oscilloscope’s default settings. This places
the oscilloscope in a known operating condition. The major default settings
are:
Table 1 Default Configuration Settings
Horizontal Normal mode, 100 s/div scale, 0 s delay, center time reference.
Vertical (Analog) Channel 1 on, 5 V/div scale, DC coupling, 0 V position, 1 M
impedance, probe factor to 1.0 if an AutoProbe probe is not connected to
the channel.
Trigger Edge trigger, Auto sweep mode, 0 V level, channel 1 source, DC
coupling, rising edge slope, 60 ns holdoff time.
Display Vectors on, 33% grid intensity, infinite persistence off.
Other Acquire mode normal,
[Run/Stop] to Run, cursors and measurements
off.
Labels All custom labels that you have created in the Label Library are
preserved (not erased), but all channel labels will be set to their original
names.
