1Getting Started
46 InfiniiVision 7000B Series Oscilloscopes User’s Guide
The overlays can also be ordered separately at www.parts.agilent.com
using the following part numbers:
Using the Oscilloscope Softkey Menus
Softkeys are the six keys directly below the display. The are called
softkeys because software determines the function assigned to each key in
any given menu.
The following graphic symbols appear in the oscilloscope’s softkey menus.
The softkey menus appear at the bottom of the display, just above the six
softkeys.
Part number Description
54695-94323 2CH Overlay - Simplified Chinese
54695-94324 4CH Overlay - Simplified Chinese
54695-94325 2CH Overlay - Traditional Chinese
54695-94326 4CH Overlay - Traditional Chinese
54695-94327 2CH Overlay - Japanese
54695-94328 4CH Overlay - Japanese
Rotate the Entry knob to adjust the parameter. The Entry knob
is located on the front panel. The symbol below the knob
is illuminated when this control is active.
Rotate the Entry knob to select an item. Push the Entry knob
or press the softkey to activate the item or close the menu.
Press the softkey to display a pop- up menu. Press the softkey
or rotate and push the Entry knob to make an item active.
Option is selected but not active.
Option is selected and active.
Feature is on. Press the softkey again to turn the feature off.
