Agilent Technologies 7000B Series - Figure 28 Example of Subtract

5 Measurements and Math Functions
190 InfiniiVision 7000B Series Oscilloscopes User’s Guide
Figure 28 Example of Subtract
Channel 1
Channel 2
1 – 2 waveform
Subtraction
operator
First
operand
Displayed
function
selected
Math
waveform
scale
Math
waveform
offset
Second
operand
