5 Measurements and Math Functions
196 InfiniiVision 7000B Series Oscilloscopes User’s Guide
Figure 31 Example of (Square Root)
Channel 1
waveform
Square
root
operator
Source
Displayed
function
selected
Math
waveform
scale
Math
waveform
offset
