Figure 7 Signals are in phase
To display the zoomed time base
Zoom, formerly called Delayed sweep mode, is a horizontally expanded
version of normal display. When Zoom is selected, the display divides in
half and the Zoom mode icon is displayed in the middle of the line at
the top of the display. The top half of the display shows the normal sweep
and the bottom half displays the Zoom sweep.
The Zoom window is a magnified portion of the normal sweep. You can
use Zoom to locate and horizontally expand part of the normal sweep for
a more detailed (higher- resolution) analysis of signals.
