7. MAINTENANCE
Direct representation Size
AT DG vari-
able_Modulo.tDetailed.*
Description
%QB(n+173)
BYTE
ARRAY(6)
Ethernet.NET1.
abyMAC
MAC NET 1 Address.
%QD(n+179)
DWORD
Ethernet.NET1.
dwPacketsSent
Counter of packets sent via NET 1 port (0 to
4294967295).
%QD(n+183)
DWORD
Ethernet.NET1.
dwPacketsReceived
Counter of packets received through NET 1 port
(0 to 4294967295).
%QD(n+187)
DWORD
Ethernet.NET1.
dwBytesSent
Count of bytes sent over NET 1 port (0 to
4294967295).
%QD(n+191)
DWORD
Ethernet.NET1.
dwBytesReceived
Count of bytes received through NET 1 port (0
to 4294967295).
%QW(n+195)
WORD
Ethernet.NET1.
wTXErrors
Counter of transmission errors via NET 1 port
(0 to 65535).
%QW(n+197)
WORD
Ethernet.NET1.
wTXFIFOErrors
Error counter in transmit buffer through NET 1
port (0 to 65535).
%QW(n+199)
WORD
Ethernet.NET1.
wTXDropErrors
Connection loss counter when transmitting
through the NET 1 port (0 to 65535).
%QW(n+201)
WORD
Ethernet.NET1.
wTXCollisionErrors
Collision error counter when transmitting via
NET 1 port (0 to 65535).
%QW(n+203)
WORD
Ethernet.NET1.
wTXCarrierErrors
Transmission error counter on NET 1 port trans-
mission (0 to 65535).
%QW(n+205)
WORD
Ethernet.NET1.
wRXErrors
Counter of errors received via NET 1 port (0 to
65535).
%QW(n+207)
WORD
Ethernet.NET1.
wRXFIFOErrors
Error counter in the receive buffer via NET 1
port (0 to 65535).
%QW(n+209)
WORD
Ethernet.NET1.
wRXDropErrors
Connection loss counter when receiving via
NET 1 port (0 to 65535).
%QW(n+211)
WORD
Ethernet.NET1.
wRXFrameErrors
Frame error counter on reception via NET 1
port (0 to 65535).
%QW(n+213)
WORD
Ethernet.NET1.
wMulticast
Counter of multicast packets through NET 1
port (0 to 65535).
Table 232: NET1 Ethernet Group Detailed Diagnostics
Direct representation Size
AT DG vari-
able_Modulo.tDetailed.*
Description
%QX(n+219).0
BIT
Ethernet.NET2.
bLinkDown
Indicates link state in NET 2.
%QW(n+220)
WORD
Ethernet.NET2.
wProtocol
Protocol selected in NET 2:
00: No protocol
%QX(n+220).0
BIT
Ethernet.NET2.
wProtocol.
bMODBUS_RTU_ETH_Client
MODBUS RTU client via TCP.
%QX(n+220).1
BIT
Ethernet.NET2.
wProtocol.
bMODBUS_ETH_Client
MODBUS TCP Client.
%QX(n+220).2
BIT
Ethernet.NET2.
wProtocol.
bMODBUS_RTU_ETH_Server
MODBUS RTU Server via TCP.
%QX(n+220).3
BIT
Ethernet.NET2.
wProtocol.
bMODBUS_ETH_Server
MODBUS TCP Server.
%QB(n+222)
STRING
(15)
Ethernet.NET2.
szIP
NET 2 IP address.
%QB(n+238)
STRING
(15)
Ethernet.NET2.
szMask
NET 2 Subnet Mask.
%QB(n+254)
STRING
(15)
Ethernet.NET2.
szGateway
NET 2 Gateway Address.
