7. MAINTENANCE
Direct representation Size
AT DG vari-
able_Modulo.tDetailed.*
Description
%QB(n+270)
STRING
(17)
Ethernet.NET2.
szMAC
MAC NET 2 address.
%QB(n+288)
BYTE
ARRAY(4)
Ethernet.NET2.
abyIP
NET 2 IP address.
%QB(n+292)
BYTE
ARRAY(4)
Ethernet.NET2.
abyMask
NET 2 Subnet Mask.
%QB(n+296)
BYTE
ARRAY(4)
Ethernet.NET2.
abyGateway
NET 2 Gateway Address.
%QB(n+300)
BYTE
ARRAY(6)
Ethernet.NET2.
abyMAC
MAC NET 2 address.
%QD(n+306)
DWORD
Ethernet.NET2.
dwPacketsSent
Counter of packets sent via NET 2 port (0 to
4294967295).
%QD(n+310)
DWORD
Ethernet.NET2.
dwPacketsReceived
Counter of packets received through NET 2 port
(0 to 4294967295).
%QD(n+314)
DWORD
Ethernet.NET2.
dwBytesSent
Count of bytes sent over NET 2 port (0 to
4294967295).
%QD(n+318)
DWORD
Ethernet.NET2.
dwBytesReceived
Count of bytes received through NET 2 port (0
to 4294967295).
%QW(n+322)
WORD
Ethernet.NET2.
wTXErrors
Counter of transmission errors via NET 2 port
(0 to 65535).
%QW(n+324)
WORD
Ethernet.NET2.
wTXFIFOErrors
Error counter in the transmission buffer through
the NET 2 port (0 to 65535).
%QW(n+326)
WORD
Ethernet.NET2.
wTXDropErrors
Connection loss counter when transmitting
through the NET 2 port (0 to 65535).
%QW(n+328)
WORD
Ethernet.NET2.
wTXCollisionErrors
Collision error counter when transmitting via
NET 2 port (0 to 65535).
%QW(n+330)
WORD
Ethernet.NET2.
wTXCarrierErrors
Transmission error counter on NET 2 port trans-
mission (0 to 65535).
%QW(n+332)
WORD
Ethernet.NET2.
wRXErrors
Counter of errors received via NET 2 port (0 to
65535).
%QW(n+334)
WORD
Ethernet.NET2.
wRXFIFOErrors
Error counter in receive buffer via NET 2 port
(0 to 65535).
%QW(n+336)
WORD
Ethernet.NET2.
wRXDropErrors
Connection loss counter when receiving via
NET 2 port (0 to 65535).
%QW(n+338)
WORD
Ethernet.NET2.
wRXFrameErrors
Frame error counter on reception via NET 2
port (0 to 65535).
%QW(n+340)
WORD
Ethernet.NET2.
wMulticast
Counter of multicast packets through NET 2
port (0 to 65535).
Table 233: NET2 Ethernet Group Detailed Diagnostics
Direct representation Size
AT DG vari-
able_Modulo.tDetailed.*
Description
%QB(n+346)
BYTE
UserFiles.
byMounted
Indicates if the memory used to write user files
is able to receive the data.
%QD(n+347)
DWORD
UserFiles.
dwFreeSpacekB
User file memory free space in Kbytes.
%QD(n+351)
DWORD
UserFiles.
dwTotalSizekB
User file memory storage capacity in Kbytes.
Table 234: Detailed Diagnostics Group UserFiles
Note:
User Partition: The user partition is a memory area reserved for data storage in the CPU. For example: files with PDF
extension, files with DOC extension and other data.
366
