455
The type of MIDI message used to work a control is selected in the Remote Control
dialog box. The options are as follows:
To Set Up Remote Control for a Knob, Button, or Fader
1. Right-click on the control and choose Remote Control from the popup menu.
2. Choose the remote control type, as described in the table above.
3. Set the note or controller number if applicable.
4. Set the MIDI Channel field to the channel that your controller sends out.
5. Click OK.
You can now work the control from your MIDI device. If you arm the control for
automation and click the Record Automation button in the SONAR Transport, you
can record your external controller’s knob or fader movements.
Message
option...
Message effect on
buttons...
Message effect on sliders
and knobs...
None No remote control No remote control
Note On The button state is toggled The slider/knob is alternately maximized
and minimized
Note On/Off The button state is toggled
when Note On is received,
and toggled again when
Note Off is received
The slider/knob is maximized when Note
On is received, and minimized when
Note Off is received
Controller Not applicable The slider/knob value is set to the
controller value
Wheel Not applicable The slider/knob value is set to the wheel
value, with the values mapped from their
original range of –8,192 to 8,191 to a
range of 0 to 127
RPN Not applicable The slider/knob value is set to the RPN
value, with the values mapped from their
original range of 0 to 16,383 to a range
of 0 to 127
NRPN Not applicable The slider/knob value is set to the NRPN
value, with the values mapped from their
original range of 0 to 16,383 to a range
of 0 to 127
