HYDRAULIC
Hydraulic Schematic Symbols
100
M2.1-00.0-004
04 Rev 9/06
Figure 3562-03
VALVE
2 way 2 position
VALVE
3 way 2 position
spring bias, solenoid control
VALVE
3 way 2 position
VALVE
4 way 2 position
VALVE
4 way 3 position
VALVE
2 way infinite positions
VALVE
4 way infinite positions
VALVE
4 way 3 position
dual spring centered,
manual lever control
NOTE: The type of valve
depends on the number of
spools found in the
component enclosure
(Triple spool valve
shown)
