ELECTRICAL
ACCESS 123...System
188
M4.3-1055-056
04 Rev. 10/09
8. Release the brake pedal and allow it to return to
the neutral position, Then press the enter arrow.
The display message will change to:
Calibration Accepted
The display will ask:
Save? N
9. Press the up/down arrow to toggle to "Y" then
press enter arrow to save calibration.
C3.4 Battery Adjust; this calibration allows the truck to
learn the actual battery voltage.
1. Press the right arrow. The display will ask:
Sure? N
2. Press the up/down arrow to toggle to "Y" then
press the enter arrow to continue. The display
message will change to:
Connect volt meter, then Enter
3. Connect a volt meter to the battery then press the
enter. The display message will momentarily
change to:
up/down adjust, Enter accepts
The display message will then change to the previ-
ous voltage setting:
XX.XX V
4. Use the up/down arrows to adjust the voltage
shown on the display to match the voltage dis-
played on the volt meter. Then press the enter ar-
row to continue. The display message will change
to:
Calibration Accepted
The display will ask:
Save? N
5. Press the up/down arrow to toggle to "Y" then
press the enter arrow to save calibration.
6. Press the left arrow to return to C3 System menu.
7. Press the up/down arrow to navigate to the C4
System menu.
C4 Height Cutout; this calibration programs a raise or
lower cutout.
Press the right arrow to continue.
C4.1 Cutout 1; this calibration programs the raise or
lower cutout.
Currently, one programmed raise or lower cutout is
available. Future software updates may permit addi-
tional cutouts.
Press the right arrow to continue.
Input Type; Since one cutout currently is available an
input type doesn't need to be selected. The factory set-
ting is LMS1 and is the only current choice available.
Press the down arrow to continue.
Cutout Type; Press the right arrow to select the appro-
priate cutout type. Use the up and down arrows to
scroll to type, then press the enter arrow to select type.
Cutout types are:
• None - No cutout.
• Raise Cutout; This cutout will cause the mast to
stop during raise when the mast reaches the cut-
out. To raise the mast beyond the cutout, the oper-
ator must press and hold the optional override
switch before raise is selected again.
• Raise Stop; This type of cutout will cause the mast
to stop during raise when the mast reaches the cut-
out. The mast cannot be raised above a Raise
Stop.
• Lower Cutout; This cutout will cause the mast to
stop during lower when the mast reaches the cut-
out. To lower the mast below the cutout, the oper-
ator must press and hold the optional override
switch before lower is selected again.
Features
Incorrectly setting Features submenus may cause an
Event Code to be logged and/or incorrect truck opera-
tion.
First, power-up truck, navigate to Service menu, select
Level 2 or 3, and enter the password. After entering the
password, use the down arrow to navigate to the FEA-
TURES menu.
Next, by pressing the right arrow you should see the
first features submenu.
If the message being displayed is too large for the
ACCESS 1 text window, the message will scroll from
right to left so the entire message can be read.
If changes have been made in the sub menus, pressing
the left arrow at the first level menu will prompt "Save?
N" in the settings. Use the up and down arrows to se-
lect Save? Y then press enter/return to save settings.
Crown 2007 PF15628-56 Rev. 10/09
