WIRING DIAGRAMS
Wire Harnesses
Wire Harnesses
Harness Components Connected By:
127272-002 * HGTS1 Harness: JC613, PC614 Trucks W/Collapsed Height Of 1805 mm (71 in)
127272-003 * HGTS1 Harness: JC613, PC614 Trucks W/Collapsed Height Of 2110 mm (83 in)
127272-004 * HGTS1 Harness: JC613, PC614 Trucks W/Collapsed Height Of 2260 mm (89 in)
127272-005 * HGTS1 Harness: JC613, PC614 Trucks W/Collapsed Height Of 2415 mm (95 in)
127272-011 * HGTS1 Harness: JC613, PC614 Trucks W/Collapsed Height Of 2565 mm (101 in)
140696 * Main Wire Harness: (Enhanced) PC201, PC202, PC203, PC204, PC205, PC206,
PC207, PC210, JC210, PC211, PC212, PC215, PC220, PC221, PC225, PC230,
PC231, PC232, PC401, PC402, PC403, PC410, PC411, PC415, PC416, PC417, PC
418, PC420, PC421, PC425, PC426, PC428, PC429, PC435, PC436, PC601, PC602,
PC605, PC608, JC610, JC611, PC613, PC617, PC621, PC625, PC627, PC629, +BV,
B-, HN1, FAN2, EDS, L Contactor, P Contactor
Travel Alarm, LGTS1, FNS, ORS, DLS
140679 * Main Wire Harness (DC Lift) PC201, PC202, PC203, PC204, PC205, PC206, PC207,
PC210, JC210, PC211, PC212, PC215, PC220, PC221, PC225, PC230, PC231,
PC232, PC401, PC402, PC403, PC405, PC415, PC417, PC 418, PC420, PC421,
PC425, PC426, PC435, PC436, PC601, PC602, PC605, PC608, JC610, JC613,
PC621, +BV, B-, HN1, FAN2, EDS, L Contactor, P Contactor
Travel Alarm, LGTS1, FNS
140680 * Main Wire Harness (AC Lift) PC201, PC202, PC203, PC204, PC205, PC206, PC207,
PC210, JC210, PC211, PC212, PC215, PC220, PC221, PC225, PC230, PC231,
PC232, PC401, PC402, PC403, PC405, PC406, PC407, PC408, PC409, PC415,
PC417, PC 418, PC420, PC421, PC425, PC426, PC435, PC436, PC601, PC602,
PC605, PC608, JC610, JC613, PC621, +BV, B-, HN1, FAN2, EDS, L Contactor, P
Contactor
Travel Alarm, LGTS1, FNS
137254 Manifold Harness: PC610, SPL, SVA2A, SVA2B, SFTR, SVTE, SVH, SPA, SVBY,
SVA1A, SVA1B
140969 Floorboard Harness: JC605, PC606, PC607, Brake Switch (BRKS)
137257 * DC Hydraulics Harness: PC405, JC410, JC411
140042 Entry Bar Switch Assembly: JC608, ENSL, ENSR
137504 * AC Hydraulics Harness: PC406, PC407, PC408, PC409, JC410, JC411
137505 * Battery Restraint Harness: BRESL or BRESR
140965 * Overhead Guard Light Harness: JC415, LGT1, LGT2
138642 * Load Sense Harness: PC611, PC612 (PT1)
140968 * Fan Harness: JC417, Operator Fan (Includes Diode Assembly)
138644 * Freezer/Corrosion Harness: PC807, PC808, PC814, +BV, -BV, RES1(EDS), High Limit
Thermostat (THS2), Ambient Thermostat (THS1)
140967-001 * Mast Work Light Harness: JC415 W/Mast Collapsed Height of 1805mm (71in)
140967-003 * Mast Work Light Harness: JC415 W/Mast Collapsed Height of 2110mm (83in)
