ELECTRICAL
Battery
206
M4.6-1055-004
4. Position battery roller stand next to truck. Align
stand with battery. Battery roller stand should be
the same height as the truck's battery compart-
ment rollers and as long as or longer than battery.
5. Roll battery onto stand. Using approved spreader
bar, lift and move battery to charging area.
Figure 16005
Figure 16006
Roll Onto
Stand
Spreader
Bar
Crown 2007 PF15687-4
