LUBRICATION & ADJUSTMENT
Lubrication and Adjustment
Refer to appropriate section of Service and Parts Man-
ual for additional information concerning inspection
and/or adjustment.
See Chart 1 and 2 for Lube Type designation explana-
tion (MA-1960-500).
Lubrication intervals must be changed to a frequency
that will minimize corrosion and wear on moving parts
for trucks operated in environments with excessive
dust and moisture, freezer/corrosion applications, etc.
Inspection Chart 1
Index Component
60 Days
250 Hours
12 Months
2000 Hours
I-1 Power Unit Wall Around Tilt Mounting Hardware (crack-free) Check
I-2 Tilt Cylinders, Pivot Points and Mounting Hardware Check
I-3 Pump Motor Brushes and Armature Condition Check
I-4 Battery Retainer Switches Operation N/A
I-5 Horn Operation N/A
I-6 Power Cable and Connections Check
I-7 Traction Motors Check
I-8 Parking Brake Operation N/A
I-9 Mast Mounting Hardware and Pivot Points Check
Lubrication Chart 1
Index Component
Lube
Type
Quantity
60 Days
250 Hours
12 Months
2000 Hours
L-1
Hydraulic Reservoir
Oil
10 Micron
Suction Strainer
Cap Ventilating Element
D 16.6 Litre (4.4 Gal)
1
1
1
Check
1st Change
1st Change
Change
Change
Clean
Change
L-2 Tilt Cylinder Zerks B As Req. Check
L-3 Drive Unit A 1 Litre (1 Qt) Check Change
L-4 Mast Pivot Zerks B As Req. Check
