Crown RC 5500 series - Work Lights - Quad Mast

541
04.8-1055-004
Always Specify Model, Data & Serial Number
ELECTRICAL PARTS
Connectors
INDEX PART NUMBER PART NAME NUMBER REQUIRED
Crown 2007 PF15625-4
(1)
Used on 140696 Enhanced All Options Harness.
(2)
Used on 140679 DC Lift Harness.
(3)
Used on 140680 AC Lift Harness.
(4)
Uses 062737-002 Crimping Tool and 062706 Extraction Tool.
Connector Part Number Chart Continued
Index Connector Designation
# of
Terminals
Terminal Insert Seal Plug
1
(1)(2)(3
062755-003
(4)
PC602 4 062797-004 062798-006 -
(1)(2)(3)
062701-005
(4)
PC605 8 062704-004 062703-010 062754-001
(1)(2)(3)
062701-003
(4)
PC606 3 062704-004 062798-004 -
(1)(2)(3)
062701-003
(4)
PC608 4 062704-004 062703-006 -
(1)
062702-001
(4)
PC611 2 062704-004 062703-001
062701-003
(4)
PC612 2 062704-008 062703-006 062754-001
(1)(2)(3)
062701-001
(4)
PC613 2 062704-004 062703-002 -
062701-001
(4)
PC614 2 062704-004 062703-002 -
(1)
062701-001
(4)
PC617 2 062704-004 062703-002 -
(1)
062701-003
(4)
PC621 4 062704-004 062703-006 -
062755-003
(4)
PC622 4 062797-012 062798-006 -
(1)
062755-001
(4)
PC625 2 062797-004 062798-002 -
(1)
062755-001
(4)
PC627 2 062797-004 062798-002 -
(1)
062701-005
(4)
PC629 8 062704-004 062703-010 -
2
(1)(2)(3)
062702-004
(4)
JC210 6 062704-003 062703-007 -
(1)
062702-006
(4)
JC410 10 062704-003 062703-011 -
(1)
062702-010
(4)
JC411 12 062704-003 062703-011 -
(1)(2)(3)
062702-002
(4)
JC415 2 062704-003 062703-003 -
(1)
062702-001
(4)
JC416 2 0622797-003 062703-001
(1)(2)(3)
062702-003
(4)
JC417 3 062704-003 062703-005 -
(1)(2)(3)
062702-005
(4)
JC605 7 062704-003 062703-009 -
(1)(2)(3)
062756-001
(4)
JC607 2 062797-003 062798-001 -
