Juniper QFX5110 Series User Manual

Figure 44: Components on the Rear Panel of EX4300-48MP and EX4300-48MP-S Switches
g022450
1
1
0
0
3
RESET
7
21 3
4
5 63
10 811 9
7—1— Empty slot for AC power supplyManagement port
8—2— QSFP+ ports (dedicated Virtual Chassis ports)ESD point
9—3— Console portFan module
10—4— Reset buttonSerial number label
11—5— USB portCLEI code label
6—AC power supply in slot 0
NOTE: The protective earthing terminal is located on the left side of the chassis. See Connect
Earth Ground to an EX Series Switch.
85

Juniper QFX5110 Series Specifications

General

Rack Units	1U
Operating System	Junos OS
Form Factor	Fixed
Management	CLI, SNMP, NETCONF
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 90% non-condensing
AC Power Input	100-240 VAC
Power Supply	Redundant, hot-swappable
