Chassis Lifting Guidelines for a QFX3500 Device
The weight of a fully loaded QFX3500 device chassis is approximately 30.8 lb (14 kg). Observe the following
guidelines for lifting and moving a QFX3500 device:
CAUTION: If you are installing the QFX3500 device above 60 in. (152.4 cm) from the
floor, you must remove the power supplies, fan trays, and management board before
attempting to install the device, or ask someone to assist you during the installation.
•
Before installing a QFX3500 device, read the guidelines in “Site Preparation Checklist for a QFX3500
Device” on page 95 to verify that the intended site meets the specified power, environmental, and
clearance requirements.
•
Before lifting or moving the QFX3500 device, disconnect all external cables.
•
As when lifting any heavy object, lift most of the weight with your legs rather than your back. Keep your
knees bent and your back relatively straight and avoid twisting your body as you lift. Balance the load
evenly and be sure that your footing is solid.
RELATED DOCUMENTATION
General Safety Guidelines and Warnings | 203
Installation Instructions Warning | 218
Mounting a QFX3500 Device in a Rack or Cabinet | 328
Chassis Lifting Guidelines for EX4300 Switches
The weight of an EX4300 switch is approximately 13 lb (5.9 kg). Observe the following guidelines for lifting
and moving the switch:
•
Before moving the switch to a site, ensure that the site meets the power, environmental, and clearance
requirements specified in the “Site Preparation Checklist for EX4300 Switches” on page 97.
•
Before lifting or moving the switch, disconnect all external cables and wires.
•
As when lifting any heavy object, ensure that most of the weight is borne by your legs rather than your
back. Keep your knees bent and your back relatively straight. Do not twist your body as you lift. Balance
the load evenly and be sure that your footing is firm.
220
