CHAPTER 39
Viewing QFX3600 System Information
IN THIS CHAPTER
Chassis Status LEDs in the QFX3600 and QFX3600-I Device | 518
Management Port LEDs in the QFX3600 and QFX3600-I Device | 520
Access Port and Uplink Port LEDs on a QFX3600 or QFX3600-I Device | 521
Fan Tray LED on a QFX3600 or QFX3600-I Device | 522
AC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device | 523
DC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device | 525
Chassis Status LEDs in the QFX3600 and QFX3600-I Device
The front panel of the QFX3600 and QFX3600-I device has three LEDs on the right side of the management
board, next to the LCD panel (see Figure 191 on page 518).
Figure 191: Chassis Status LEDs in the QFX3600 and QFX3600-I Device
Table 89 on page 519 describes the chassis status LEDs in a QFX3600 and QFX3600-I device, their colors
and states, and the status they indicate. You can view the colors of the three LEDs remotely through the
CLI by issuing the operational mode command show chassis lcd.
